General Specifications
2710mm (W) x 765mm (D) x 1835mm (H)
Electrical 415V 25 Amp 3 Phase
Weight 525Kg
Warranty 5 years parts warranty on the cabinet, 2 years parts warranty on the wash pump and a comprehensive 1 year parts and labour warranty
-
Features
High volume up to 240 racks per hour (4,320 plate equivalents)
Low cold water consumption of 120 litres per hour
In-house CAD design service for every site layout
Integrated heat recovery unit with significantly reduces steam emissions, energy consumption and water treatment cost
SEED certified for installation without an extraction canopy in most situations
Four stage EcoRinse for exceptional rinse performance and minimal water usage
Full thermal and acoustic insulation
Heavy-duty stainless steel construction, wash manifold and full width easily removable wash filter trays
Removable upper and lower heavy duty stainless steel wash arm cassettes
Powerful drive with safety clutch allows the machine to wash heavy items with ease
Autostart minimises operating costs by only activating pumps and drive when a rack is present
Will wash items up to 400mm high and taller with suitable operator procedures
600mm pre-wash module with multi-layer externally removable scrap trays
1200mm wash module with 3-stage EcoRinse
600mm EcoRinse module with dual recirculating and final rinse stages
Dual speed drive with options of slower (DIN 10510 2-minute contact time) or faster settings available
Digital temperature gauges for easy HACCP reporting
Watermark approved backflow prevention
