General Specifications
450mm (W) x 805mm (D) x 1130mm (H)
Gas Natural 2 x 28MJ
Weight 108Kg
1 Year Parts and Labour Warranty
-
Features
Heavy-duty construction
28 MJ/hr open burners
Flame failure standard
Pilot burners optional
300mm griddle plate option
Optional simmer plates
Stainless steel exterior
Easy clean
Easy service
Fully modular
Low back models (RNL) available
Welded hob with 1.5mm 304 stainless steel bull nose
Splashback and side panels 1.2mm 304 stainless steel
Front panels 0.9mm 304 stainless steel
Aluminised steel internal construction
Cast iron 28MJ/hr open burners with forged brass cap
Vitreous enamelled cast iron potstands
Vitreous enamelled open burner spill cover
Cast iron simmer plates (optional extra)
12mm thick mild steel griddle plate
2.5mm 304 stainless steel griddle splash guards
Vitreous enamelled spill trays Bench mount (supplied as –B model)
Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs with adjustable feet.
Adjustable height 80mm – 105mm Controls
Variable high to low controls to open burners
Open burners flame failure standard with pilot burners optional
Variable high to low controls to griddles
Griddles standard with pilot, flame failure and piezo ignition
Large easy use control knob - heat resistant reinforced
Easy view control settings on knob Cleaning and Ser vicing
All models with easy clean stainless steel external finish
Lift off burners heads and vitreous enamelled burner spill covers
Vitreous enamelled spill trays under open burner and griddle section
Access to all parts from front of uni
