General Specifications
675mm (W) x 626mm (D) x 890mm (H)
Electrical Oven 230-240V, 50Hz, 1P+N+E, 3.1kW, 12.9A 15A 3-pin cordset fitted
Electrical Cooktop 230-240V, 50Hz, 1P+N+E, 7.0kW, 29.2A Supply connection to unit required
Weight 78.6kg
1 Year Parts and Labour Warranty
-
Features
Compact 675mm width x 626mm depth
Single phase 15A plug-in oven
Single phase connection cooktop COOKTOP
Two 2kW high speed front hot-plate elements
Two 1.5kW high speed rear hot-plate elements
Full hygienic pressed stainless steel top
6-heat setting element controls
1-phase 7kW connection OVEN
4 Gastronorm GN 1/1 pan capacity
80mm tray spacing
Mechanical thermostat 50° - 270°C
60 minute timer with time-up buzzer
Grill mode • Single direction low-velocity fan
2.8kW heating in bake mode / 2kW grill elements
Safe-Touch vented side hinged door (standard LH hinge).
Optional RH hinge (field convertible)
Stay-Cool door handle
Vitreous enamel oven chamber
Plug-in continuous oven door seal
Halogen oven lamp
50mm dia. adjustable stainless steel legs
4 oven wire racks supplied
15A plug-in cordset fitted
100% recyclable packagin
